CPI Diplexer 114391-8

CPI 114391-8 C-Band RX-Only Diplexer | 3.4–4.2 GHz | CP/LP | 2-Port

The CPI 114391-8 is a receive-only 2-port C-band diplexer designed for circular or linear polarization satellite downlink systems. Operating from 3.4 to 4.2 GHz, it delivers low insertion loss, excellent axial ratio, and a sealed design ideal for professional SATCOM environments.

Key Features:

Frequency Range (Rx): 3.4–4.2 GHz

Polarization: Circular or Linear (CP/LP)

Insertion Loss (Rx): ≤0.25 dB

VSWR: ≤1.25:1

Isolation: ≥20 dB

Axial Ratio: ≤0.50 dB

Pressurization: Sealed to 1.0 PSIG

Finish:
    Flange Faces: Chromate conversion coated (MIL-DTL-5541F, Type II, Class 1A)
    Exterior: White paint (FED-STD-595, Color 17875)
