Peak ILA Series Rack Mounted IF, L-Band & SHF Line Amplifiers

Peak Communications ILA Series Rack Mounted IF, L-Band & SHF Line Amplifiers

Peak Communications ILA Series Rack Mounted Line Amplifiers provide high-quality signal amplification for satellite earth station and across-site applications. Available for IF, UHF, L-Band, S-Band, C-Band, Ku-Band, and DBS-Band frequencies, the 1U amplifiers deliver excellent gain flatness and stability with 20 dB standard gain and optional 30, 40, or 50 dB gain configurations. Optional features include variable attenuation, slope compensation, RF monitoring, 10 MHz reference pass-through, fiber optic L-Band interfaces, redundant power supplies, and redundancy system compatibility.

Key Features

• 19-inch 1U rack-mounted line amplifiers

• Frequency coverage from 50 MHz to 18.4 GHz, depending on model

• IF, UHF, L-Band, S-Band, C-Band, Ku-Band and DBS-Band models

• 20 dB minimum standard gain

• Optional 30, 40 and 50 dB gain

• High gain flatness and stability

• Amplifier low-current alarm monitoring

• Optional 30 dB manual variable attenuation

• Optional L-Band slope compensation

• Optional 10 MHz reference pass-through

• Optional RF monitor and fiber optic L-Band interfaces

• Optional redundant power supplies

• Compatible with Peak 1+1, 2+1 and N+1 redundancy systems
