Peak DLA200 Dual Hot-Swap Line Amplifier

Peak Communications DLA200 Dual Hot-Swap Line Amplifier

Peak Communications DLA200 Dual Hot-Swap Line Amplifier is a modular 19-inch 1U rack-mounted system supporting two line amplifier modules for 70/140 MHz IF, UHF, L-Band, S-Band, C-Band, Ku-Band, and DBS-Band signals. Modules can be replaced from the rear without removing power or disturbing the other channel. The DLA200 provides high gain flatness and stability, redundant power supplies, amplifier alarm monitoring, and optional integral 1+1 redundancy for high-availability satellite communication systems.

Key Features:

• Dual modular hot-swappable line amplifier

• Supports two MLA amplifier modules

• 70/140 MHz IF through 18.4 GHz frequency coverage, depending on module

• IF, UHF, L-, S-, C-, Ku-, and DBS-Band configurations

• Standard gain: 20 dB minimum

• Optional 30 dB or 40 dB gain

• High gain flatness and stability

• Amplifier low-current alarm monitoring

• Redundant power supplies with dual AC inputs

• Optional integral 1+1 module redundancy

• Redundancy switching time <150 ms

• Optional L-Band 10 MHz reference pass-through

• Optional L-Band slope compensation

• Optional 2-way or 4-way input combiner/output splitter

• Optional input and output monitor ports

• RS232/RS485 remote control

• Optional Ethernet, embedded web server and SNMP

• Optional 48 VDC power supply
