Peak DLAH200 Dual Hot-Swap Variable Gain Line Amplifier

Peak Communications DLAH200 Dual Hot-Swap Variable Gain Line Amplifier

Peak Communications DLAH200 Dual Hot-Swap Variable Gain Line Amplifier is a modular 19-inch 1U rack-mounted system supporting two line amplifier modules for IF, UHF, L-Band, S-Band, C-Band, Ku-Band, and DBS-Band signals. Hot-swappable modules can be replaced from the rear without removing power or disturbing the other channel. The DLAH200 features a graphics display and keypad, high gain flatness and stability, redundant power supplies, and optional variable gain, 1+1 redundancy, signal power monitoring, and slope compensation.

Key Features:

• Dual modular hot-swappable line amplifier

• IF through 18.4 GHz frequency coverage, depending on module

• IF, UHF, L-, S-, C-, Ku-, and DBS-Band configurations

• Standard gain: 20 dB minimum

• Optional 30 dB or 40 dB gain

• Optional 30 dB variable gain in 0.1 or 0.5 dB steps

• Graphics display and membrane keypad

• High gain flatness and stability

• Amplifier low-current alarm monitoring

• Redundant power supplies with dual AC inputs

• Optional integral 1+1 redundancy

• Redundancy switching time <150 ms

• Optional output chassis mute with >80 dB isolation

• Optional input or output signal power detector and alarms

• Optional passive or active L-Band slope compensation

• Optional L-Band 10 MHz reference pass-through

• Optional 2-way or 4-way input combiner/output splitter

• RS232/RS485 remote control

• Optional Ethernet, embedded web server and SNMP
