Peak VGU010 10-Channel Variable & Fixed Gain Unit

Peak Communications VGU010 10-Channel Variable & Fixed Gain Unit

Peak Communications VGU010 10-Channel Variable & Fixed Gain Unit is a modular 2U rack-mounted system providing gain and attenuation control for IF, L-Band, and SHF signals. Supporting up to 10 hot-swappable variable attenuation or fixed gain modules, the VGU010 is ideal for balancing cross-site cable losses and remotely adjusting satellite earth station uplink and downlink signal levels. It features Ethernet remote control, full alarm monitoring, redundant hot-swappable power supplies, and optional slope compensation, fail-safe bypass, and splitter/combiner modules.

Key Features:

• 1 to 10 independent modular channels

• Hot-swappable MVG variable attenuation and MFG fixed gain modules

• IF, L-Band, and SHF frequency configurations

• Frequency coverage from 50 MHz to 12.75 GHz, depending on module

• Variable attenuation: 0–30 dB in 0.1 dB steps

• Fixed gain: 20 dB nominal

• Optional fixed gain of 30 or 40 dB

• Optional MVG gain of 15 or 27 dB

• Ethernet remote control

• Full channel and power supply alarm monitoring

• Dual redundant, modular hot-swappable power supplies

• Optional fail-safe bypass switching

• Optional DC and 10 MHz pass-through

• Optional passive or active L-Band slope compensation

• Supports optional 4-way and 8-way passive splitter/combiner modules

• Suitable for earth station uplink/downlink gain balancing

• SHF configurations suitable for 5G network coverage and capacity layer testing
