Peak PLAH Series Remote Mounted L-Band Line Amplifiers

Peak Communications PLAH Series Remote Mounted L-Band Line Amplifiers

Peak Communications PLAH Series Remote Mounted L-Band Line Amplifiers provide adjustable amplification and slope compensation for 950–2150 MHz satellite IF links and cross-site installations. Available in single- and dual-channel Tx and Rx configurations, the PLAH Series features user-variable gain and slope control, Ethernet remote management, high gain flatness and stability, and rugged IP66 weatherproof construction for outdoor installation.

Key Features:

• Remote-mounted 950–2150 MHz L-Band line amplifiers

• Single- and dual-channel configurations

• Dedicated Tx and Rx optimized versions

• Standard gain: 20 dB minimum

• Optional 30 dB or 40 dB gain

• User-variable gain and slope compensation

• 0–8 dB positive active slope compensation

• Variable attenuation included with active slope control

• Ethernet remote control standard

• Embedded web server and SNMP support

• Optional PLAH-LC handheld local controller

• High gain flatness and stability

• Amplifier low-current alarm monitoring

• Optional 10 MHz reference pass-through

• Optional DC pass-through for BUC, BDC or LNB powering

• Wide +16.5 to +35 VDC input range

• Rugged die-cast aluminum IP66 enclosure

• Operating temperature: −25°C to +55°C

• Optional low-temperature operation to −40°C
