Peak RTR51 Remote Mounted CW Beacon Tracking Receiver

Peak Communications RTR51 Remote Mounted CW Beacon Tracking Receiver

Peak Communications RTR51 Remote Mounted CW Beacon Tracking Receiver is designed for fast acquisition, tracking, and level measurement of CW satellite beacons. Featuring a 945–2150 MHz L-Band input, 1 kHz tuning resolution, a 2 kHz PLL tracking system, and sophisticated digital sideband rejection, the RTR51 provides fast signal acquisition and accurate logarithmic level output. Its rugged IP66 weatherproof housing and Ethernet remote control make it suitable for earth stations, antenna tracking systems, and SOTM/mobile applications.

Key Features:

• Remote-mounted CW satellite beacon tracking receiver

• 945–2150 MHz L-Band input

• Other frequency ranges including S-Band available on request

• Fast signal acquisition and locking

• Average acquisition time <1 second under specified search conditions

• 1 kHz frequency step size

• 2 kHz PLL tracking bandwidth

• Search ranges from ±20 to ±500 kHz

• Sophisticated digital sideband rejection

• User-selectable logarithmic DC output

• ±10 VDC tracking output

• Ethernet remote control standard

• Embedded web server and SNMP network management

• Optional RS232/RS485 interface

• Optional +16 VDC BDC/LNB power

• Summary failure and out-of-lock alarms

• Rugged aluminum IP66 weatherproof enclosure

• Operating temperature −10°C to +50°C

• Optional low-temperature operation to −40°C
