Peak PRP2150 Remote Mounted CW Pilot Generator

Peak Communications PRP2150 Remote Mounted CW Pilot Generator

Peak Communications PRP2150 Remote Mounted CW Pilot Generator provides a highly stable L-Band CW pilot signal for AUPC and satellite beacon tracking applications when a suitable satellite beacon is unavailable. Covering 850–2150 MHz, the PRP2150 features precise 125 kHz frequency steps, wide output level control, a high-stability internal 10 MHz reference, Ethernet/SNMP remote management, and a rugged IP66 weatherproof enclosure for outdoor installation.

Key Features:

• Remote-mounted CW pilot generator

• Designed for AUPC and beacon tracking applications

• Extended L-Band output: 850–2150 MHz

• Frequency resolution: 125 kHz

• Output level: −50 to −80 dBm

• Output adjustment in 0.5 dB steps

• Excellent output level stability over temperature and time

• High-stability ovenized crystal oscillator

• Internal 10 MHz reference

• Optional higher-stability internal reference

• Optional external 10 MHz reference with automatic detection

• Ethernet remote control standard

• Embedded web server and SNMP network management

• Optional RS232/RS485 interface

• Summary failure and out-of-lock alarms

• Rugged die-cast aluminum construction

• IP66-rated weatherproof enclosure

• Operating temperature: −25°C to +55°C

• Optional operation down to −40°C
