Peak Communications PTR50 CW Tracking Receiver

Peak Communications PTR50 CW Tracking Receiver is a high-performance beacon tracking receiver designed to acquire, track, and measure CW beacon signals from commercial satellites. Supporting standard L-Band and optional SHF inputs, the PTR50 features fast signal acquisition, graphical beacon spectrum display, logarithmic signal output, and optional Ethernet management for satellite telemetry, antenna control, and automatic uplink power control systems. It is ideal for teleport, gateway, military, broadcast, and satellite earth station applications.

Key Features:

• 19-inch 1U rack-mounted CW beacon tracking receiver

• Tracks and measures commercial satellite CW beacon signals

• Standard L-Band input with optional C-, X-, Ku-, and Ka-Band inputs

• Graphical beacon spectrum display

• Fast signal acquisition and tracking (typically 6 s, optional <1 s)

• High-stability frequency reference with 1 kHz tuning resolution

• Optional pilot CW signal generator

• User-selectable logarithmic DC output

• Ethernet, web server, and SNMP management options

• Compatible with Peak B1000L redundancy systems

• Ideal for teleport, gateway, military, broadcast, and satellite earth station applications
