Actox ABE20UDBS / ABE20UDBSF
Full DBS-band 20W BUC
• RF Frequency: 17.3 to 18.4 GHz
• IF Frequency: 950 to 1700 MHz
• Double LO: Switchable 16.35 & 16.85 GHz
• IF Connector: N (50Ω) or F type (75Ω)
• Output Power: +43 dBm min.
Security policy
Delivery policy
Return policy
Actox ABE20UDBS / ABE20UDBSF – 20W 17.3–18.4 GHz Full DBS-Band BUC
This unique smallest and lightest 20W L-To DBS-Band Block Up Converter covers the full DBS-Band frequencies (17.3-18.4 GHz). M&C (FSK) capability enables trouble shooting, monitoring and controlling the BUC. Internal 10MHz reference option enables using the BUC with the modems without 10MHz reference.
Key Features
RF Frequency: 17.3 – 18.4 GHz
Output Power: 20W (+43 dBm min.)
Double L.O. (electronically and manually switchable 16.35 and 16.85 GHz)
IF Frequency: 950 – 1700 MHz
Extreme P-Out GaN linearity
Incomparable low power consumption (127W max.)
Auto-ranging powering option 15 - 60 VDC
High power efficiency
Digital temperature compensation
Field-exchangeable (F/N) IF connector
Power and lock status LED
Autosensing and controllable internal 10MHz reference (optional)
Advanced M&C - combined RS-232/485 / Ethernet (HTTP and SNMP ver. 2 & 3) / FSK (optional)
Special Feature: Chinese GUI (optional)
Mechanical & Environmental
Dimensions: 190 × 140 × 58 mm
Weight: 2.53 kg max.
IP67 outdoor-rated enclosure
Operating temperature: -40°C to +55°C
Applications
VSAT uplink systems
Broadcast uplinks
Teleport infrastructure
Remote satellite communication terminals
Government and military SATCOM systems
ABE20UDBS, ABE20UDBSF
- Transmit Band
- 17.30 - 18.40 GHz
- Power Output
- 20W
