Actox ABE6KXHM / ABE6KXHMF
Extended Ku-band 6W mini-BUC
• RF Frequency: 13.75 to 14.5 GHz
• IF Frequency: 950 to 1700 MHz
• Double LO: Switchable 12.8 & 13.05 GHz
• IF Connector: N (50Ω) or F type (75Ω)
• Output Power: +38 dBm min.
Security policy
Delivery policy
Return policy
Actox ABE6KXHM / ABE6KXHMF – 6W Extended 13.75–14.5 GHz Ku-Band BUC
This smallest and lightest 6W L-To Ku-Band Block Up Converter is based on GaN technology. Double L.O. and field-exchangeable connectors make the unit universal for any Ku-Band application. Incomparable low power consumption allows the BUC to be powered by iDirect and similar modems. Internal 10MHz reference option enables using the BUC with the modems without 10MHz reference.
Key Features
RF Frequency: 13.75 – 14.5 GHz
Output Power: 6W (+38 dBm min)
Double L.O. (switchable 12.80 & 13.05 GHz)
IF Frequency: 950 – 1700 MHz
GaN technology for high efficiency and reliability
Incomparable low power consumption (35W max.)
Advanced M&C - combined RS-232/485 / Ethernet (HTTP and SNMP ver. 2 & 3) / FSK (optional)
Auto-ranging powering option 15 - 60 VDC
Digital temperature compensation
Field-exchangeable (F/N) IF connector
Power and lock status LED
Built-in redundancy option
Internal 10MHz high stability reference (optional)
RoHS compliant
Mechanical & Environmental
Dimensions: 140 × 120 × 69.5 mm
Weight: 1.2 kg max.
Vibration/Shock: MIL-STD-810E compliant
IP67 outdoor-rated enclosure
Operating temperature: -40°C to +55°C
Applications
VSAT uplink systems
Broadcast uplinks
Teleport infrastructure
Remote satellite communication terminals
Government and military SATCOM systems
ABA6KXHH
- Transmit Band
- 13.75 - 14.50 GHz
- Power Output
- 6W
Specific References
Extended Ku-band 6W mini-BUC
• RF Frequency: 13.75 to 14.5 GHz
• IF Frequency: 950 to 1700 MHz
• Double LO: Switchable 12.8 & 13.05 GHz
• IF Connector: N (50Ω) or F type (75Ω)
• Output Power: +38 dBm min.
