ETL Systems GRIFFIN GRF-202 2×1 Optical Redundancy Switch Module

ETL Systems GRIFFIN GRF-202 2×1 Optical Redundancy Switch Module

The ETL Systems GRIFFIN GRF-202 provides 2×1 optical redundancy switching for single-mode fibre signals over 1240–1640 nm. Its latching switch design offers less than 1.8 dB optical insertion loss and 60 dB minimum optical isolation. The module occupies one slot in a compatible GRIFFIN chassis and is available with SC-APC or FC-APC connectors.

Optical Wavelength Range: 1240–1640 nm
Switch Configuration: 2×1 optical redundancy switch
Fibre Type: Single mode
Switch Type: Latching
Connector Options: SC-APC or FC-APC
Optical Insertion Loss: <1.8 dB
Optical Return Loss: 40 dB
Optical Isolation: 75 dB typ.; 60 dB minimum
Monitoring: Optical switch current
Module Slots Used: One
Installation: Within a compatible GRIFFIN chassis

Key Features

• 2×1 switching between primary and backup optical signal paths

• Single-mode fibre operation across 1240–1640 nm

• Latching optical switch design

• Less than 1.8 dB optical insertion loss

• 60 dB minimum optical isolation

• SC-APC and FC-APC connector options

Requires a compatible GRIFFIN chassis. Specify the optical connector type when requesting a quotation.
