Peak P7613 Dual-Band C & Ku-Band Up Converter

Peak Communications P7613 Dual-Band C & Ku-Band Up Converter

Peak Communications P7613 Dual-Band C & Ku-Band Up Converter provides fully synthesized frequency conversion from 70 MHz or 140 MHz IF to Extended C-Band and Ku-Band in a single rack-mounted unit. With internally switched 5.85–6.65 GHz C-Band and 13.75–14.5 GHz Ku-Band output ranges, the P7613 features a standard L-Band interface, IESS-308/309 compliance, adjustable attenuation, automatic external reference locking, and integrated redundancy control for professional satellite communication systems.

Key Features:

• Fully synthesized multi-band up converter

• Dual Extended C-Band and Ku-Band operation

• Extended C-Band output: 5.85–6.65 GHz

• Ku-Band output: 13.75–14.5 GHz

• Internal frequency-range switching

• Single RF input and output connection

• Standard 70 ±18 MHz IF input

• Optional 140 ±36 MHz IF input

• Standard 950–1750 MHz L-Band input

• Optional auxiliary L-Band output

• +30 dB conversion gain

• 0–30 dB attenuation in 0.1 dB steps

• 1 Hz synthesizer resolution

• Output mute with >80 dB isolation

• IESS-308/309 compliant

• Supports high-order modulation schemes above 100 Mbit/s

• Automatic external 5 or 10 MHz reference detection and locking

• Integrated 1+1 and 2+1 CANBUS® redundancy control

• N+1 redundancy systems available

• Optional Ethernet, embedded web server and SNMP

• Optional redundant power supplies
