Peak IBUH(A) Series Rack Mounted Block Up Converter

Peak IBUH(A) Series Rack Mounted Block Up Converter

The Peak Communications IBUH(A) Series is a family of high-performance rack mounted block up converters (BUCs) designed for professional SATCOM earth stations, teleports, broadcast uplink facilities, and defense communication systems. Available in C-Band, X-Band, Ku-Band, DBS-Band, and INSAT frequency ranges, the IBUH(A) Series converts L-Band signals into SHF uplink frequencies with exceptional phase noise, frequency stability, and RF performance.

Built around externally phase-locked dielectric resonator oscillator (XPDRO) technology, the IBUH(A) Series delivers significantly better frequency stability and lower phase noise than conventional VCO-based block up converters. The converters feature a full front-panel graphical user interface, Ethernet and serial remote control, automatic external 10 MHz reference locking, integrated CANBUS® 1+1 and 2+1 redundancy control, and optional N+1 redundancy support. Optional input power monitoring, variable attenuation, RF mute, test loop translator, L-Band monitoring, and fiber optic interfaces make the IBUH(A) Series ideal for mission-critical satellite communication infrastructure.

Key Features

• High-performance rack mounted Block Up Converter (BUC)

• Available in C-Band, INSAT C-Band, X-Band, Ku-Band, INSAT Ku-Band, and DBS-Band

• Models available in single, dual, triple, and quad-channel configurations

• High-stability XPDRO oscillator technology

• Automatic 10 MHz external reference detection and internal reference backup

• Front-panel graphical display with intuitive keypad interface

• Ethernet, SNMP, RS-232, and RS-485 remote management (optional Ethernet/SNMP)

• Integrated CANBUS® 1+1 and 2+1 redundancy controller

• Optional N+1 redundancy systems

• Optional RF monitor ports, input power detector, RF mute, variable attenuation, test loop translator, fiber optic L-Band interface, and slope compensation

• Compliant with IESS-308 / IESS-309 specifications and suitable for high-order modulation systems exceeding 100 Mbps
