Peak IBUH(Ka) Series Rack Mounted Ka-Band Block Up Converter

Peak IBUH(Ka) Series Rack Mounted Ka-Band Block Up Converter

The Peak Communications IBUH(Ka) Series is a family of high-performance rack mounted Ka-Band Block Up Converters (BUCs) designed for professional satellite earth stations, teleports, gateway hubs, broadcast uplink facilities, and government SATCOM applications. Available in both single-range and multi-range Ka-Band configurations, the IBUH(Ka) Series converts L-Band signals into Ka-Band uplink frequencies with outstanding frequency stability, low phase noise, and exceptional RF performance.

Featuring a full front-panel graphical user interface, Ethernet and serial remote control, automatic 10 MHz external reference locking, and integrated CANBUS® 1+1 and 2+1 redundancy control, the IBUH(Ka) Series provides the flexibility required for mission-critical satellite communication systems. Optional features including input power monitoring, variable attenuation, fiber optic L-Band interface, redundant power supplies, and SNMP management make these converters ideal for modern Ka-Band gateway and teleport infrastructure.

Key Features

• High-performance rack mounted Ka-Band Block Up Converter (BUC)

• Available in single-range and multi-range Ka-Band models

• Ka-Band output frequencies from 19.70 GHz to 31.00 GHz

• Supports professional Ka-Band gateway, teleport, and SATCOM applications

• Front-panel graphical display with intuitive keypad interface

• Automatic 10 MHz external reference locking with internal backup reference

• Ethernet, SNMP, RS-232, and RS-485 remote management

• Integrated CANBUS® 1+1 and 2+1 redundancy controller

• Optional N+1 redundancy systems

• Optional input power monitoring, fiber optic L-Band interface, variable attenuation, and redundant power supplies

• Available in dual-, triple-, and quad-channel configurations for high-capacity systems
