Peak IBDH(Ka) Series Rack Mounted Ka-Band Block Down Converter

Peak IBDH(Ka) Series Rack Mounted Ka-Band Block Down Converter

The Peak Communications IBDH(Ka) Series is a family of high-performance rack mounted Ka-Band Block Down Converters (BDCs) designed for professional satellite earth stations, gateway hubs, teleports, broadcast receive facilities, and government SATCOM applications. Available in single-range, multi-range, and multi-channel configurations, the IBDH(Ka) Series converts Ka-Band RF signals into L-Band outputs for direct connection to satellite receivers, demodulators, and advanced IF conversion systems.

Engineered for demanding satellite communication networks, the IBDH(Ka) Series delivers exceptional frequency stability, low phase noise, and excellent RF performance. The converters feature automatic 10 MHz external reference locking, integrated CANBUS® 1+1 and 2+1 redundancy control, front-panel graphical user interface, Ethernet and serial remote management, and optional fiber optic L-Band interface, redundant power supplies, and electronic attenuation. Available in dual-, triple-, and quad-channel versions, the IBDH(Ka) Series is ideal for modern Ka-Band gateway and HTS ground infrastructure.

Key Features

• High-performance rack mounted Ka-Band Block Down Converter (BDC)

• Available in single-range, multi-range, and multi-channel configurations

• Ka-Band receive coverage from 17.7 GHz to 22.0 GHz

• Ground test and ranging models covering 27.5 GHz to 31.0 GHz

• Available in dual-, triple-, and quad-channel versions

• Automatic 10 MHz external reference with internal backup reference

• Front-panel graphical display and keypad interface

• Ethernet, SNMP, RS-232, and RS-485 remote management

• Integrated CANBUS® 1+1 and 2+1 redundancy controller

• Optional N+1 redundancy systems

• Optional fiber optic L-Band interface, redundant power supplies, L-Band monitor ports, and electronic attenuation

• Designed for professional Ka-Band satellite communication and gateway applications
