Peak DBU200(Ka) Dual Hot-Swap Ka-Band Block Converter

Peak Communications DBU200(Ka) Dual Hot-Swap Ka-Band Block Converter

Peak Communications DBU200(Ka) Dual Hot-Swap Ka-Band Block Converter is a 19-inch 1U rack-mounted chassis supporting any combination of two Ka-Band BUC or BDC converter modules. Modules can be replaced from the rear without removing power or interrupting the other channel. The DBU200(Ka) features redundant power supplies, automatic external 10 MHz reference locking with internal backup, full alarm monitoring, and optional integral 1+1 module redundancy for high-availability satellite communication systems.

Key Features:

• Dual-module Ka-Band block converter chassis

• 19-inch 1U rack-mounted design

• Supports any mix of two MBU BUC or MBD BDC modules

• Hot-swappable rear-access converter modules

• Module replacement without powering down or disturbing the other channel

• Ka-Band frequency options from 18.2 to 31.0 GHz, depending on module

• L-Band to Ka-Band BUC modules available

• Ka-Band to L-Band BDC modules available

• High stability, low ripple and excellent phase noise

• External 10 MHz reference with automatic internal reference backup

• Redundant power supplies with dual AC inputs standard

• Full alarm monitoring

• Optional integral 1+1 module redundancy

• Redundancy switching speed <150 ms

• Compatible with Peak RCU Series external redundancy systems

• Optional Ethernet, embedded web server and SNMP

• Optional 48 VDC power supply
