Peak DBUH200(Ka) Dual Hot-Swap Ka-Band Block Converter

Peak Communications DBUH200(Ka) Dual Hot-Swap Ka-Band Block Converter

Peak Communications DBUH200(Ka) Dual Hot-Swap Ka-Band Block Converter is a 19-inch 1U rack-mounted system supporting any combination of two Ka-Band BUC or BDC converter modules. Modules can be inserted or replaced from the rear without removing power or disturbing the other channel. The DBUH200(Ka) features a graphics display and keypad, redundant power supplies, automatic external 10 MHz reference locking with internal backup, full alarm monitoring, and optional integral 1+1 redundancy for high-availability satellite communication systems.

Key Features:

• Dual hot-swappable Ka-Band block converter system

• Supports any mix of two BUC or BDC modules

• 19-inch 1U rack-mounted chassis

• L-Band to Ka-Band BUC conversion

• Ka-Band to L-Band BDC conversion

• Ka-Band module coverage from 17.7 to 31.0 GHz

• Graphics display and membrane keypad

• High stability, low ripple and excellent phase noise

• External 10 MHz reference with automatic internal backup

• Redundant power supplies with dual mains inputs

• Full LO, PSU and amplifier alarm monitoring

• Optional 0–30 dB variable gain in 0.5 dB steps

• Optional integral 1+1 module redundancy

• Redundancy switching time <150 ms

• Optional chassis mute with 70 dB isolation

• Optional Ethernet, embedded web server and SNMP

• Optional 48 VDC prime power
