Peak F1202R Remote Mounted IF to L-Band Up Converter

Peak F1202R Remote Mounted IF to L-Band Up Converter

The Peak Communications F1202R is a fixed-frequency remote mounted IF to L-Band up converter designed for professional satellite earth stations, teleports, broadcast uplink facilities, and legacy SATCOM infrastructure. It converts 70 MHz ±18 MHz IF (or optional 140 MHz ±36 MHz) to a fixed 1200 MHz L-Band output, providing a simple and economical solution for interfacing 70 MHz or 140 MHz modems and transceivers with modern L-Band satellite equipment.

Engineered for reliable outdoor operation, the F1202R features a rugged IP66 weatherproof enclosure, automatic 10 MHz external reference locking with a high-stability internal backup oscillator, and compliance with IESS-306 and IESS-309 requirements. Supporting 1+1 and 2+1 redundancy configurations, the converter delivers excellent phase noise performance and frequency stability for professional fixed satellite communication networks.

Key Features

• Fixed-frequency remote mounted IF to L-Band up converter

• Standard 70 MHz ±18 MHz IF input

• Optional 140 MHz ±36 MHz IF input

• Fixed 1200 MHz L-Band output

• Automatic 10 MHz external reference with internal backup

• Compliant with IESS-306 and IESS-309

• Supports 8PSK and 16QAM modulation above 50 Mbps

• Available in 1+1 and 2+1 redundancy configurations

• Rugged IP66 weatherproof die-cast aluminum enclosure

• Low phase noise and excellent frequency stability
