Peak TLTH(A) Series Single-Band Test Loop Translators

Peak Communications TLTH(A) Series Single-Band Test Loop Translators

Peak Communications TLTH(A) Series Single-Band Test Loop Translators convert a sample of a satellite transmit signal to L-Band or another receive frequency for signal monitoring, analysis, and system testing. Available for S-, C-, X-, Ku-, and DBS-Band applications, the TLTH(A) Series features a full local user interface, RS232/RS485 remote control, excellent phase noise, full alarm monitoring, and optional electronic attenuation, Ethernet/SNMP control, external reference, and RF mute.

Key Features:

• Single-band test loop translators for satellite signal monitoring

• S-, C-, X-, Ku-, and DBS-Band configurations

• Converts transmit signals to L-Band or corresponding receive bands

• 19-inch 1U rack-mounted chassis

• Full front-panel local user interface

• RS232/RS485 remote control standard

• Optional Ethernet, embedded web server and SNMP

• High stability and excellent phase noise

• Full alarm monitoring

• Typical conversion loss: 20 dB ±2 dB

• Optional 0–30 dB electronic attenuation

• Optional external 10 MHz reference input

• Optional RF mute with ≥60 dB isolation

• Optional redundant power supply

• Built-in 1+1 and 2+1 redundancy controller

• CANBUS® interface for N+1 redundancy systems
