Peak TLTH(B) Series Single-Band Test Loop Translators

Peak Communications TLTH(B) Series Multi-Band Test Loop Translators

Peak Communications TLTH(B) Series Multi-Band Test Loop Translators convert samples of satellite transmit signals to L-Band or corresponding receive bands for signal monitoring, analysis, and system testing. Supporting multi-band configurations across C-, X-, Ku-, and Ka-Band, the TLTH(B) Series features internal band switching, a full local user interface, RS232/RS485 remote control, excellent phase noise, full alarm monitoring, and optional electronic attenuation, Ethernet/SNMP, and RF mute.

Key Features:

• Multi-band test loop translators for satellite signal monitoring

• Internal switching between multiple frequency bands

• C-, X-, Ku-, and Ka-Band configurations

• Transmit-to-L-Band and transmit-to-receive-band translation

• Dual-, tri-, and quad-band configurations available

• Single wideband input and output standard

• Optional multiple inputs and outputs

• 19-inch 1U rack-mounted chassis

• Full front-panel local user interface

• RS232/RS485 remote control standard

• Optional Ethernet, embedded web server and SNMP

• High stability and excellent phase noise

• Full alarm monitoring

• Optional 0–30 dB electronic attenuation

• Optional external 10 MHz reference input

• Optional RF mute with ≥60 dB isolation

• Built-in 1+1 and 2+1 redundancy controller

• CANBUS® interface for N+1 redundancy systems
