Peak TLTH(Ka) Series Ka-Band Test Loop Translators

Peak Communications TLTH(Ka) Series Ka-Band Test Loop Translators

Peak Communications TLTH(Ka) Series Ka-Band Test Loop Translators convert samples of Ka-Band transmit signals to L-Band or Ka-Band receive frequencies for satellite signal monitoring, analysis, and system testing. Covering Ka-Band transmit frequencies from 27.5 to 31.0 GHz, the series features a full local user interface, RS232/RS485 remote control, high stability, excellent phase noise, full alarm monitoring, and optional electronic attenuation, external reference, Ethernet/SNMP, and redundant power supply.

Key Features:

• Ka-Band test loop translators for TX signal monitoring

• Ka-Band TX coverage from 27.5 to 31.0 GHz

• Ka-Band TX to L-Band conversion

• Full Ka-Band TX to Ka-Band RX conversion available

• 19-inch 1U rack-mounted chassis

• Full front-panel local user interface

• RS232/RS485 remote control standard

• High stability and excellent phase noise

• Full alarm monitoring

• 20 dB ±2 dB conversion loss

• Optional 0–30 dB electronic attenuation

• Optional external 10 MHz reference input

• Optional Ethernet, embedded web server and SNMP

• Built-in 1+1 and 2+1 redundancy controller

• CANBUS® interface for N+1 redundancy systems

• Optional redundant power supply
