Peak Communications DTL200 Dual Hot-Swap Test Loop Translator

Peak Communications DTL200 Dual Hot-Swap Test Loop Translator is a modular 19-inch 1U rack-mounted system supporting two Test Loop Translator modules for satellite signal monitoring and testing. Modules can be inserted or replaced from the rear without removing power or interrupting the other channel. Supporting S-, C-, X-, Ku-, and DBS-Band configurations, the DTL200 features redundant power supplies, high stability, excellent phase noise, remote control, and optional integral 1+1 module redundancy.

Key Features:

• Dual modular Test Loop Translator system

• Two hot-swappable MTL converter modules

• Module replacement without powering down the chassis

• S-, C-, X-, Ku-, and DBS-Band configurations

• TX-to-L-Band and TX-to-receive-band translation options

• 19-inch 1U rack-mounted chassis

• High stability and excellent phase noise

• Redundant power supplies with dual AC inputs standard

• RS232/RS485 remote control

• Optional Ethernet, embedded web server and SNMP

• Optional external 10 MHz reference input

• Optional integral 1+1 module redundancy

• Redundancy switching time <150 ms

• 60 dB switch isolation

• Optional 48 VDC prime power
