Peak DTLH200 Dual Hot-Swap Test Loop Translator

Peak Communications DTLH200 Dual Hot-Swap Test Loop Translator

Peak Communications DTLH200 Dual Hot-Swap Test Loop Translator is a modular 19-inch 1U rack-mounted system supporting two Test Loop Translator modules for satellite signal monitoring and testing. Modules can be inserted or replaced from the rear without removing power or disturbing the other channel. Supporting S-, C-, X-, Ku-, and DBS-Band configurations, the DTLH200 features a graphics display and keypad, redundant power supplies, high stability, excellent phase noise, remote control, and optional integral 1+1 module redundancy.

Key Features:

• Dual modular Test Loop Translator system

• Two rear-access hot-swappable MTLH modules

• Module replacement without powering down the chassis

• S-, C-, X-, Ku-, and DBS-Band configurations

• TX-to-L-Band and TX-to-receive-band translation

• 19-inch 1U rack-mounted chassis

• Graphics display and keypad

• High stability and excellent phase noise

• Redundant power supplies with dual AC inputs

• RS232/RS485 remote control

• Optional Ethernet, embedded web server and SNMP

• Optional external 10 MHz reference input

• Optional 30 dB variable attenuation for L-/S-Band

• Optional integral 1+1 module redundancy

• Redundancy switching time <150 ms

• 60 dB switch isolation
• Optional output chassis mute with >80 dB isolation

• Optional 48 VDC prime power
