iDirect FRC0710 Upconverter

iDirect FRC0710 Upconverter

The iDirect FRC0710 Upconverter is a high-performance frequency conversion solution designed for satellite uplink, broadcast, and telecom applications.

It converts IF signals (70/140 MHz) to L-band and optional RF bands, delivering excellent frequency stability, high linearity, and low phase noise. The FRC0710 is ideal for reliable uplink operations across a wide range of satcom environments.

Key Features

IF to L-band and RF upconversion

Optional output to C-band, Ku-band, DBS-band

High frequency stability and low phase noise

High linearity across full bandwidth

Fine frequency resolution tuning

Remote control via Web GUI and SNMP

Compact and integration-friendly design

Key Specifications

IF Input: 70 / 140 MHz

L-band Output: ~950 – 2150 MHz

RF Output: C, Ku, DBS (optional)

Gain: Programmable

Interfaces: IF, L-band, RF

Control: Web GUI, SNMP

Applications

Satellite uplink systems

Broadcast transmission

Teleport infrastructure

SNG (Satellite News Gathering)
