iDirect FRC0730 Up/Downconverter

iDirect FRC0730 Up/Downconverter

The iDirect FRC0730 Up/Downconverter combines both upconversion and downconversion in a single compact unit, offering a flexible solution for satellite, broadcast, and telecom systems.

With support for IF, L-band, and RF conversions, it delivers high frequency stability, excellent linearity, and versatile deployment options, making it ideal for integrated satcom infrastructures.

Key Features

Combined upconverter and downconverter

Supports IF, L-band, and RF conversions

Optional C-band, Ku-band, DBS-band support

High stability and low phase noise

High linearity across bandwidth

Remote control via Web GUI and SNMP

Space-saving, integrated design

Key Specifications

IF Range: 70 / 140 MHz

L-band: ~950 – 2150 MHz

RF Bands: C, Ku, DBS (optional)

Conversion: Bi-directional (Up & Down)

Interfaces: IF, L-band, RF

Control: Web GUI, SNMP

Applications

Teleport systems

Satellite gateways

Broadcast infrastructure

Integrated satcom systems
