iDirect FRC0750 Active L-Band Combiner & Upconverter

The iDirect FRC0750 Active L-band Combiner and Upconverter is a flexible solution designed to combine multiple L-band signals and optionally upconvert them to RF frequencies for satellite transmission.

It supports combining up to four or eight L-band inputs, with individual gain control for each channel, making it ideal for multi-carrier satellite systems and redundancy applications.

Key Features

Combines up to 4 or 8 L-band signals

Optional integrated RF upconversion (C, Ku, DBS)

Individual gain control for each input

Supports signal routing and redundancy switching

Optional 10 MHz reference and DC power for BUC

High stability and signal integrity

Advanced monitoring via Web GUI and SNMP

Key Specifications

Inputs: Up to 4 (standard) or 8 (optional) L-band

Frequency Range: 950 – 2150 MHz

Output: L-band or RF (optional upconversion)

Gain: Adjustable per input

Reference: 10 MHz input/output (optional)

Control: Web GUI, SNMP

Applications

Multi-carrier satellite uplinks

Broadcast distribution systems

Teleport and gateway infrastructure

Redundancy and signal routing systems

VSAT hub environments
