Peak P7025 Series Ku-Band to IF Down Converter

Peak P7025 Series Ku-Band to IF Down Converter

The Peak Communications P7025 Series Ku-Band to IF Down Converters are fully synthesised satellite frequency converters designed for professional SATCOM earth stations, teleports, and broadcast reception systems. The converters translate Ku-Band signals to IF outputs of 70 MHz ±18 MHz or 140 MHz ±36 MHz, delivering reliable signal conversion for satellite receivers and modem systems.

The P7025 Series supports wide Ku-Band coverage from 10.70 GHz to 12.75 GHz, with selectable sub-bands depending on the model variant. The unit incorporates a standard L-Band interface, enabling compatibility with mixed 70 MHz, 140 MHz, and L-Band infrastructures, while allowing easy upgrades to modern L-Band networks.

Designed for demanding SATCOM environments, the converter offers excellent RF stability, low phase noise, and high dynamic range, making it suitable for high-order modulation and high-data-rate digital communications. Integrated CANBUS redundancy control, automatic locking to an external 10 MHz reference, and a graphical front-panel interface ensure reliable operation in professional satellite ground station deployments.
