Peak P7600 Series IF to Multi-Band Up Converter

Peak P7600 Series IF to Multi-Band Up Converter

The Peak Communications P7600 Series IF to Multi-Band Up Converters are fully synthesised satellite frequency converters designed for professional SATCOM earth stations, teleports, and broadcast uplink systems. The converters translate 70 MHz ±18 MHz or 140 MHz ±36 MHz IF signals into RF uplink frequencies, delivering stable and precise frequency conversion for modern satellite communication networks.

The P7613 model within the P7600 series provides dual-band operation, supporting Extended C-Band (5.85–6.65 GHz) and Wide Ku-Band (13.75–14.5 GHz) uplink ranges within a single unit. Internal band switching allows operators to select the desired RF band through the front-panel interface or remote control, enabling flexible multi-band uplink deployments.

The converter includes a standard L-Band interface, allowing compatibility with mixed 70 MHz, 140 MHz, and L-Band infrastructures while enabling easy upgrades to L-Band systems. Integrated CANBUS redundancy control, automatic locking to an external 10 MHz reference, and a graphical front-panel control interface ensure reliable operation in demanding ground station environments.
