13.0m Antenna

Ku-Band 4-Port 2Tx/2Rx

Quantity

Request for Quotation

Your Query is sent.

  •     *Required Fields

Loading



Security policy



Delivery policy



Return policy

The 13.0m antenna system, designed and manufactured with CAD, can be applied to the newly updated INTELSAT (IESS) standard earth station. The antenna system consists of dual shaped Cassegrain reflectors, a frequency reuse feed network with corrugated horn, an elevation-over-azimuth limit motion kingpost pedestal. The backup structure for the reflector, the hub connecting the main reflector with mount and the pedestal provides the guaranteed pointing accuracy required in normal operation.

The main reflector diameter consists of 80 precision stretch formed aluminum panels riveted with the rings and radials in three rings.

Antenna system is characteristic of high gain, low sidelobes, low cross polarization, capable for frequency reuse both in transmit and receive bands, high driving/control accuracy with angle position display in high resolution.

The radiation patterns meet the associated requirements of INTELSAT (IESS), FCC and CCIR for 2 degree spacing location of geostationary satellites.

Frequency Range
Rx: 10.95 - 12.75 GHz
Frequency Range
Tx: 13.75 - 14.5 GHz
Gain
Rx: 62.6 dB min.; Tx: 63.6 dB min.
Antenna Noise Temperature
73K @ 10° Elevation
Antenna Noise Temperature
50K @ 40° Elevation
Antenna Noise Temperature
87K @ 5° Elevation
Antenna Noise Temperature
65K @ 20° Elevation
Pattern Beamwidth -3dB
Rx: 0.13°; Tx: 0.11°
V S W R
Rx: 1.3: 1; Tx: 1.3: 1
Sidelobe Pattern
First sidelobe level less than -14dB
Sidelobe Pattern
Beyond first sidelobe meet IESS(Intelsat) or CCIR 580-4 Recommendation
Cross Pol. Discrimination
35dB (On axis) ; 30dB (within 1 dB Beamwidth)
Feed Insertion Loss
Rx: 0.50 dB; Tx: 0.60 dB
Power Handling Capability
1 KW CW (2 KW high power option) per port
Port to Port Isolation
Tx/Rx: 85 dB min. (with TRF)
Port to Port Isolation
Rx/Rx: 30 dB min.
Port to Port Isolation
Tx/Tx: 30 dB min.
Feed Interfaces
Rx: WR75F; Tx: WR75F
Azimuth Travel
180° in two 100° in overlapping sectors continuous
Azimuth Travel Rate
0.1°/second
Elevation Travel
0 to 90°
Elevation Travel Rate
0.1°/second
Polarization Travel
±45°
Polarization Travel Rate
1.0°/second
Reflector
Steel
Backup Structure
Steel
Pedestal Structure
Steel
Operation Wind
45 mph (72 km/h) gusts to 60 mph (97 km/h)
Survival Wind
200km/h
Ambient Temperature
Operational: -15°C to +50°C
Ambient Temperature
Survival: -30°C to +60°C
Rain
up to 4 in/h (10 cm/h), lasting 10 minutes
Relative Humidity
up to 100%
Radial Ice (Survival)
25mm on all surface or 13mm on all surface with 130km/h wind gusts
Shock & Vibration
As encountered during shipment by commercial air, sea or truck
Corrosive atmosphere
As encountered in coastal regions and/or heavily industrialized areas
Seismic (Survival)
0.1G’s vertical
Seismic (Survival)
0.3G’s horizontal
