CPI LKE12S65-XXXX

Ku-Band 10.95–12.75 GHz LNA

Quantity

Request for Quotation

Your Query is sent.

  •     *Required Fields

Loading



Security policy



Delivery policy



Return policy

LKE12S65-XXXX Ku-Band LNA | 10.95–12.75 GHz , 65 K Noise Temp, 60 dB Gain

The CPI LKE12S65-XXXX is a high-performance Ku-band low noise amplifier covering 10.95–12.75 GHz with a guaranteed 65 K noise temperature across the band. Designed for fixed and transportable SATCOM systems, it features a minimum gain of 60 dB, +12 dBm output power, and robust thermal stability. The LNA includes an internal isolator, SMA output connector, and operates on +12 to +24 VDC. CE-certified and RoHS compliant, it is ideal for high-reliability ground station installations.

Key Features:

Frequency: 10.95–12.75 GHz
Noise Temperature: 65 K typ. (guaranteed)
Gain: 60 dB min. / 64 dB typ.
Output Power (P1dB): +12 dBm min.
Power Input: +12 to +24 VDC
Output Connector: SMA female
Built-in input/output isolators and reverse polarity protection
CE certified, RoHS compliant
Applications:

Ku-band earth station receiver front ends

Fixed and mobile SATCOM terminals

High-reliability commercial and military ground systems

LKE12S65-XXXX
Frequency Range
10.95–12.75 GHz
Noise Temperature
65 K
Gain
60 dB
Output Power
+12 dBm
Power Configuration
+12 to +24 Vdc
RF Out Connector
SMA Female
