LKE12S70-XXXX Ku-Band LNA | 10.95–12.75 GHz, 70 K Noise Temp, 60 dB Gain
The CPI LKE12S70-XXXX is a Ku-band low noise amplifier engineered for satellite earth station receivers operating in the 10.95–12.75 GHz range. With a guaranteed noise temperature of 70 K and minimum gain of 60 dB, it delivers reliable low-noise performance for both fixed and transportable SATCOM systems. This unit includes an SMA female output, operates on +12 to +24 VDC, and features built-in isolators and reverse polarity protection.
Key Features:
Frequency Range: 10.95–12.75 GHz
Noise Temperature: 70 K typ. (guaranteed)
Gain: 60 dB min.
Output Power: +12 dBm min.
Power Supply: +12 to +24 VDC
Connector: SMA female
Internal isolator, reverse polarity protection
CE certified and RoHS compliant
Applications:
Ku-band SATCOM ground station front ends
Broadcast and VSAT terminals
Fixed and mobile LNA installations
LKE12S70-XXXX
- Frequency Range
- 10.95–12.75 GHz
- Noise Temperature
- 70 K
- Gain
- 60 dB
- Output Power
- +12 dBm
- Power Configuration
- +12 to +24 Vdc
- RF Out Connector
- SMA Female
