Norsat 1008DXF-1 – Ku-Band Simultaneous Dual-Band External Reference LNB, F-Type (75Ω)
$2,048.00
Covers 10.70–12.75 GHz in two simultaneous sub-bands:
• Band 1: 10.70–11.70 GHz
• Band 2: 11.70–12.75 GHz
• LO Reference: External 10 MHz
• Noise Figure: 0.8 dB
• Output Connector: F-type, 75 Ω
Security policy
Delivery policy
Return policy
Norsat 1008DXF-1 Ku-Band Simultaneous Band External Reference LNB
The Norsat 1008DXF-1 is a Ku-Band simultaneous band PLL LNB designed for dual-band operation with an external 10 MHz reference. It delivers typ. 0.8 dB noise figure, wide 10.70–12.75 GHz coverage, and rugged reliability for professional SATCOM links.
Band: Ku-Band (Simultaneous Low/High)
Input Frequency: 10.70–11.70 GHz (Low), 11.70–12.75 GHz (High)
Output Frequency: 950–1950 MHz (Low), 950–2000 MHz (High)
LO Frequencies: 9.75 GHz (Low), 10.75 GHz (High)
LO Stability: External Reference
Noise Figure: typ. 0.8 dB, max. 0.85 dB
Conversion Gain: typ. 55 dB (50–62 dB), ≤4 dB flatness
Output P1dB: +5 dBm min.
Input Connector: WR-75 waveguide
Output Connector: F-Type, 75 Ohm
Power: +12 to +24 VDC, 450 mA max per band
Environmental: -40°C to +60°C operating; IP-rated design
Dimensions: 155 × 42 × 40 mm; Weight: 0.45 kg
Country of Origin: Republic of Korea; ECCN: EAR99; HS Code: 8517690000
1008DXF-1
- Type
- Single LNBs
- Frequency Band
- Ku-Band
- Frequency Range
- 10.70 – 12.75 GHz
- Number of Bands
- 2-Band
- Sub-Band
- Band 1: 10.7–11.7 GHz
- Sub-Band
- Band 2: 11.7–12.75 GHz
- Output Band
- Band 1: 950 – 1950 MHz
- Output Band
- Band 2: 950 – 2000 MHz
- LO Frequency
- Multiple LO
- LO Stability
- External Reference
- Noise Figure
- 0.8 dB
- Typical Gain
- 55 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- F Type 75 Ohm
