Norsat 1208HUN – Ku-Band Quad-Band PLL LNB, N-Type (50Ω)
$1,100.00
Covers 10.70–12.75 GHz in four sub-bands:
• Band 1: 10.70–11.70 GHz
• Band 2: 10.95–11.70 GHz
• Band 3: 11.70–12.75 GHz
• Band 4: 12.25–12.75 GHz
• LO Stability: ±25 kHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
Security policy
Delivery policy
Return policy
Norsat 1208HUN Ku-Band Quad-Band PLL LNB
The Norsat 1208HUN is a high-performance Ku-Band quad-band PLL LNB with ±25 kHz stability. It supports four onboard local oscillators for full 10.70–12.75 GHz coverage and offers typ. 0.8 dB noise figure, rugged IP67 protection, and flexible voltage/tone control for professional SATCOM systems.
Band: Ku-Band (Quad-Band)
Input Frequencies: 10.70–11.70 GHz, 10.95–11.70 GHz, 11.70–12.75 GHz, 12.25–12.75 GHz
Output Frequencies: 950–1950 MHz, 950–1700 MHz, 950–2000 MHz, 950–1450 MHz
LO Frequencies: 9.75 / 10.00 / 10.75 / 11.30 GHz
LO Stability: ±25 kHz
Noise Figure: typ. 0.8 dB, max. 1.0 dB
Gain: typ. 60 dB (55–65 dB), ≤5 dB flatness
Output P1dB: +5 dBm min.
Control: 13 V/18 V with or without 22 kHz tone
Input Connector: WR-75 waveguide
Output Connector: N-Type, 50 Ohm
Power: +12 to +24 VDC, 350 mA max
Environmental: -40°C to +60°C operating; IP67 rated
Dimensions: 128 × 60 × 42 mm; Weight: 0.45 kg
Country of Origin: Republic of Korea
ECCN: EAR99; HS Code: 8517690000
1208HUN
- Type
- Single LNBs
- Frequency Band
- Ku-Band
- Frequency Range
- 10.70 – 12.75 GHz
- Number of Bands
- 4-Band
- Sub-Band
- Band 4: 12.25–12.75 GHz
- Sub-Band
- Band 3: 11.7–12.75 GHz
- Sub-Band
- Band 2: 10.95–11.7 GHz
- Sub-Band
- Band 1: 10.7–11.7 GHz
- Output Band
- Band 1: 950 – 1950 MHz
- Output Band
- Band 2: 950 – 1700 MHz
- Output Band
- Band 4: 950 – 1450 MHz
- Output Band
- Band 3: 950 – 2000 MHz
- LO Frequency
- Multiple LO
- LO Stability
- ±25 kHz
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- N Type 50 Ohm
