Norsat 9500HTBCDF – Ka-Band Triple-Band PLL LNB, F-Type (75Ω)
$2,000.00
Covers 19.20 – 22.20 GHz in three sub-bands:
• Band 1: 19.20 - 20.20 GHz
• Band 2: 20.20 - 21.20 GHz
• Band 3: 21.20 - 22.20 GHz
• LO Stability: ±50 kHz
• Noise Figure: 1.5 dB
• Output Connector: F Type 75 Ohm
• Voltage/tone control: 13/18 V DC with 22 kHz Tone Switching
Security policy
Delivery policy
Return policy
Norsat 9500HTBCDF Ka-Band Triple-Band PLL LNB
The Norsat 9500HTBCDF is a Ka-Band triple-band PLL LNB designed for reliable SATCOM downlinking. Covering 19.20–22.20 GHz across three bands, it provides ±50 kHz stability, low typ. 1.5 dB noise figure, and rugged IP67 protection for dependable performance in challenging environments.
Band: Ka-Band (Triple-Band)
Input Frequencies: 19.20–20.20 GHz, 20.20–21.20 GHz, 21.20–22.20 GHz,
Output Frequencies: 950–1950 MHz (all bands)
LO Frequencies: 18.25 / 19.25 / 20.25 GHz
LO Stability: ±50 kHz (PLL)
Noise Figure: typ. 1.5 dB, max. 1.8 dB
Conversion Gain: typ. 60 dB (55–65 dB range), ≤5 dB flatness
Output P1dB: +3 dBm min.
Phase Noise: -95 dBc/Hz @100 kHz offset
Control: 13 V (Band 1), 18 V (Band 2), 18 V + 22 kHz tone (Band 3)
Input Connector: WR-42 waveguide, grooved
Output Connector: F-Type, 75 Ohm
Power: +12 to +24 VDC, 450 mA max
Environmental: -40°C to +60°C operating; -40°C to +80°C storage; IP67 rated
Dimensions: 120 × 60 × 45 mm; Weight: 0.42 kg
Country of Origin: Republic of Korea
ECCN: EAR99; HS Code: 8517690000
9500HTBCDF
- Type
- Single LNBs
- Frequency Band
- Ka-Band
- Frequency Range
- 19.20 – 22.20 GHz
- Number of Bands
- 3-Band
- Sub-Band
- Band 1: 19.2–20.2 GHz
- Sub-Band
- Band 2: 20.2–21.2 GHz
- Sub-Band
- Band 3: 21.2–22.2 GHz
- Output Band
- Band 1: 950 – 1950 MHz
- Output Band
- Band 2: 950 – 1950 MHz
- Output Band
- Band 3: 950 – 1950 MHz
- LO Frequency
- Multiple LO
- LO Stability
- ±50 kHz
- Noise Figure
- 1.5 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- F Type 75 Ohm
