Norsat 2108HDDF – Ku-Band Dual-Band PLL LNB, F-Type (75Ω)
$760.00
Covers 10.70–12.75 GHz across two sub-bands:
• Band 1: 10.70–11.70 GHz
• Band 2: 11.70–12.75 GHz
• LO Stability: ±10 kHz
• Noise Figure: 0.8 dB
• Output Connector: F-type, 75 Ω
• Voltage/tone control: 13/18 V DC
Security policy
Delivery policy
Return policy
Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world and offer premium performance and reliability in the smallest form factor possible. All of Norsat standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs. 2009 Series.
2108HDDF
- Frequency Band
- Ku-Band
- Frequency Range
- 10.70 – 12.75 GHz
- Number of Bands
- 2-Band
- Sub-Band
- Band 1: 10.70 – 11.70 GHz
- Sub-Band
- Band 2: 11.70 – 12.75 GHz
- Output Band
- Band 1: 950 – 1950 MHz
- Output Band
- Band 2: 1100 – 2150 MHz
- LO Frequency
- Multiple LO
- LO Stability
- ±10 kHz
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- F Type 75 Ohm
- Control
- 13/18 V DC
Specific References
Covers 10.70–12.75 GHz across two sub-bands:
• Band 1: 10.70–11.70 GHz
• Band 2: 11.70–12.75 GHz
• LO Stability: ±10 kHz
• Noise Figure: 0.8 dB
• Output Connector: F-type, 75 Ω
• Voltage/tone control: 13/18 V DC
