Norsat 9000XICDF
$1,858.00
Ka-Band Dual-Band Ext. Ref. LNB
9000XA Series
Band 1: 20.2–21.2 GHz
Band 2: 21.2–22.2 GHz
LO Reference: External 10 MHz
Output Connector: F Female, 75 Ohm
Integrated Waveguide Isolator: Yes
Security policy
Delivery policy
Return policy
Norsat 9000XICDF Ka-Band Dual-Band PLL EXT LNB
The Norsat 9000XICDF is a Ka-Band dual-band LNB supporting 20.2 to 22.2 GHz reception. It features an external 10 MHz PLL reference, WR-42 input, F-type 75 Ohm output, and integrated isolator—ideal for stable, low-noise Ka-CD band SATCOM applications.
Input Frequency Ranges:
Band 1: 20.2 – 21.2 GHz
Band 2: 21.2 – 22.2 GHz
Output Frequency (Both Bands): 950 – 1950 MHz
LO Frequencies: 19.25 / 20.25 GHz
LO Stability: External 10 MHz reference
Noise Figure: typ. 1.8 dB (max. 1.5 dB)
Conversion Gain: typ. 60 dB (min. 55 dB, max. 65 dB)
Control Signals: 13V / No Tone (Band 1), 18V / No Tone (Band 2)
Gain Flatness: ≤ 5 dB p-p
Image Rejection: ≥ 40 dBc
Output P1dB: ≥ +5 dBm
VSWR (Input / Output): max. 2.5:1
Phase Noise: Depends on external reference
RF Input Connector: WR-42
IF Output Connector: F-Type 75 Ohm
Integrated Isolator: Yes
Power Supply: +12 to +24 VDC
9000XICDF
- Input Band
- 20.2–21.2 GHz
- Input Band
- 21.2–22.2 GHz
- LO Frequency
- 19.25 GHz
- LO Frequency
- 20.25 GHz
- LO Stability
- External Reference
Specific References
Ka-Band Dual-Band Ext. Ref. LNB
9000XA Series
Band 1: 20.2–21.2 GHz
Band 2: 21.2–22.2 GHz
LO Reference: External 10 MHz
Output Connector: F Female, 75 Ohm
Integrated Waveguide Isolator: Yes
