Norsat 9000XICDN – Ka-Band Dual-Band External Reference LNB
$1,858.00
Covers 20.2–22.2 GHz input range
Supports 2 sub-bands:
• Band 1: 20.2–21.2 GHz
• Band 2: 21.2–22.2 GHz
• LO Reference: External 10 MHz
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: Yes
Security policy
Delivery policy
Return policy
Norsat 9000XICDN Ka-Band Dual-Band PLL EXT LNB
The Norsat 9000XICDN is a Ka-Band dual-band LNB supporting 20.2 to 22.2 GHz reception. It features an external 10 MHz PLL reference, WR-42 input, N-type 50 Ohm output, and integrated isolator—ideal for stable, low-noise Ka-CD band SATCOM applications.
Input Frequency Ranges:
Band 1: 20.2 – 21.2 GHz
Band 2: 21.2 – 22.2 GHz
Output Frequency (Both Bands): 950 – 1950 MHz
LO Frequencies: 19.25 / 20.25 GHz
LO Stability: External 10 MHz reference
Noise Figure: typ. 1.8 dB (max. 1.5 dB)
Conversion Gain: typ. 60 dB (min. 55 dB, max. 65 dB)
Control Signals: 13V / No Tone (Band 1), 18V / No Tone (Band 2)
Gain Flatness: ≤ 5 dB p-p
Image Rejection: ≥ 40 dBc
Output P1dB: ≥ +5 dBm
VSWR (Input / Output): max. 2.5:1
Phase Noise: Depends on external reference
RF Input Connector: WR-42
IF Output Connector: N-Type 50 Ohm
Integrated Isolator: Yes
Power Supply: +12 to +24 VDC
9000XICDN
- Frequency Band
- Ka-Band
- Frequency Range
- 20.20 – 22.20 GHz
- Number of Bands
- 2-Band
- Sub-Band
- Band 1: 20.20 – 21.20 GHz
- Sub-Band
- Band 2: 21.20 – 22.20 GHz
- Output Band
- Band 1: 950 – 1950 MHz
- Output Band
- Band 2: 950 – 1950 MHz
- LO Frequency
- Multiple LO
- LO Stability
- External Reference
- Noise Figure
- 1.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- N Type 50 Ohm
Specific References
Covers 20.2–22.2 GHz input range
Supports 2 sub-bands:
• Band 1: 20.2–21.2 GHz
• Band 2: 21.2–22.2 GHz
• LO Reference: External 10 MHz
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: Yes
