Norsat 9000XIAN-2 – Ka-Band Single-Band External Reference PLL LNB
$1,629.00
• Input Band: 18.2–19.2 GHz
• LO Reference: External 10 MHz
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: Yes
Security policy
Delivery policy
Return policy
Norsat 9000XIAN-2 Ka-Band Single-Band PLL EXT LNB
The Norsat 9000XIAN-2 is a Ka-Band LNB designed for 18.2 to 19.2 GHz reception. It features an external 10 MHz PLL reference, WR-42 input, N-type 50 Ohm output, and integrated isolator—engineered for precision and reliability in Ka-A band satellite systems.
Input Frequency: 18.2 – 19.2 GHz
Output Frequency: 950 – 1950 MHz
LO Frequency: 17.25 GHz
LO Stability: External 10 MHz reference
Noise Figure: typ. 1.5 dB (max. 1.6 dB)
Conversion Gain: typ. 60 dB (min. 55 dB, max. 65 dB)
Gain Flatness: ≤ 4 dB p-p
Phase Noise: Depends on external reference
Output P1dB: ≥ +5 dBm
Image Rejection: ≥ 40 dBc
VSWR (Input / Output): max. 1.5:1 / 2.5:1
RF Input Connector: WR-42
IF Output Connector: N-Type 50 Ohm
Integrated Isolator: Yes
Power Supply: +12 to +24 VDC
Current Consumption: max. 350 mA
Operating Temp: –40°C to +60°C
IP Rating: IP67
Dimensions: 98.7 × 42.4 × 42.2 mm
Weight: 0.27 kg
9000XIAN-2
- Frequency Band
- Ka-Band
- Frequency Range
- 18.20 – 19.20 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1950 MHz
- LO Frequency
- 17.25 GHz
- LO Stability
- External Reference
- Noise Figure
- 1.5 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 18.2–19.2 GHz
• LO Reference: External 10 MHz
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: Yes
