Ka-Band Low Noise Block Converter

Model: TLNB20000AS.0007

The CPI TLNB-20000AS is a high-performance Ka-Band Low Noise Block (LNB) Converter engineered for fixed and transportable SATCOM systems. Featuring ultra-low noise temperature, phase-locked LO, and robust HEMT/GaAs FET design, it ensures excellent signal reception in harsh environments. Operating from 20.2–21.2 GHz input with a 1000–2000 MHz IF output, it includes reverse polarity protection, internal/external reference switching, and outstanding gain flatness and stability. Ideal for demanding receiver applications in satellite communications.

Frequency Range: 20.2–21.2 GHz (Input)

IF Output: 1000–2000 MHz

Gain: typ. 63 dB

Noise Temp: typ. 110 K

LO Stability: ±29 kHz (internal ref)

Power: +12 to +22 VDC, typ. 400 mA

Connector: WR42 input, Type-N output

Operating Temp: -40°C to +70°C

CPI TLNB20000AS.0007
Input Band
20.2–21.2 GHz
