CPI TLNB7500X.0005

X-Band Low Noise Block Converter

Quantity

Request for Quotation

Your Query is sent.

  •     *Required Fields

Loading



Security policy



Delivery policy



Return policy

The CPI TLNB-7500X.0005 is a high-performance X-Band Low Noise Block Converter engineered for SATCOM receiver applications. Designed for both fixed and transportable systems, it features a phase-locked oscillator, excellent phase noise, and superior noise temperature performance. With GaAs FET and HEMT technology, this LNB ensures reliable, low-noise downlink signal reception across the 7.25–7.75 GHz band.

Key Features:

Input Frequency: 7.25–7.75 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 6.30 GHz
Noise Temperature: 45 K typ., 50 K max
Gain: 60–66 dB
Output P1dB: +15 to +18 dBm
External 10 MHz reference required
Power: +12 to +22 VDC, 450 mA max
Temperature Range: –40°C to +70°C
Input: CPR112G flange | Output: Type N (F)
Reverse polarity protection

CPI TLNB7500X.0005
Input Band
7.25-7.75 GHz
