Norsat 4208AN – Ku-Band Single-Band PLL LNB, N-Type (50Ω)
$146.00
• Input Band: 11.70–12.20 GHz
• LO Stability: ±250 kHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
Security policy
Delivery policy
Return policy
Norsat 4208AN Single-Band Ku-Band PLL LNB
The Norsat 4208AN is a single-band Ku-Band PLL LNB with ±250 kHz LO stability and a typ. 0.8 dB noise figure, engineered for reliable downlinking from 11.70 to 12.20 GHz. It features a 50 Ohm N-type output, WR-75 waveguide input, and IP67-rated protection for dependable SATCOM performance in all weather conditions.
Frequency Band: 11.70–12.20 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 10.75 GHz
LO Stability: ±250 kHz
Noise Figure: typ. 0.8 dB, max. 0.9 dB
Gain: typ. 60 dB (55–70 dB range), ≤4 dB p-p flatness
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide grooved
Power: +15 to +24 VDC, 300 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 85 x 43 x 43 mm; Weight: 0.2 kg
Made in Republic of Korea; ECCN: EAR99
4208AN
- Type
- Single LNBs
- Frequency Band
- Ku-Band
- Frequency Range
- 11.70 – 12.20 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1450 MHz
- LO Frequency
- 10.75 GHz
- LO Stability
- ±250 kHz
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- N Type 50 Ohm
