Norsat 15007LAN – Ku-Band Single-Band PLL LNB, N-Type (50Ω)

Norsat 15007LAN Single-Band Ku-Band PLL LNB

The Norsat 15007LAN is a single-band Ku-Band PLL LNB with ±50 kHz LO stability and a typ. 0.7 dB noise figure, designed for precision downlinking from 11.70 to 12.20 GHz. It features a 50 Ohm N-type output, WR-75 waveguide input, and compact IP-rated housing for reliable SATCOM operation in harsh environments.

Frequency Band: 11.70–12.20 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 10.75 GHz
LO Stability: ±50 kHz
Noise Figure: typ. 0.7 dB, max. 0.8 dB
Gain: typ. 60 dB (55–65 dB range)
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide grooved
Power: +15 to +24 VDC, 170 mA max
Environmental: -40°C to +60°C, 0–95% humidity
Dimensions: 110 x 42 x 42 mm; Weight: 0.3 kg
Made in Republic of Korea; ECCN: EAR99
