Norsat 1209HAN – Ku-Band Single-Band PLL LNB, N-Type (50Ω)

Norsat 1209HAN Single-Band Ku-Band PLL LNB

The Norsat 1209HAN is a single-band Ku-Band PLL LNB with ±25 kHz LO stability and a typ. 0.9 dB noise figure, engineered for precision downlinking from 11.70 to 12.20 GHz. It features a 50 Ohm N-type output, WR-75 waveguide input, and IP67-rated protection for reliable SATCOM operation in harsh environments.

Frequency Band: 11.70–12.20 GHz

Output Frequency: 950–1450 MHz
Local Oscillator: 10.75 GHz
LO Stability: ±25 kHz
Noise Figure: typ. 0.9 dB, max. 1.0 dB
Gain: typ. 60 dB (55–65 dB range), ≤4 dB p-p flatness
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide grooved
Power: +12 to +24 VDC, 300 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 110 x 42 x 42 mm; Weight: 0.3 kg
Made in Republic of Korea; ECCN: EAR99
