Norsat 1008XEN – Ka-Band Single-Band External Reference PLL LNB, N-Type (50Ω)
$1,694.00
• Input Band: 10.95–12.75 GHz
• LO Reference: External 10 MHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
Security policy
Delivery policy
Return policy
Norsat 1008XEN Single-Band Ku-Band External Reference LNB
The Norsat 1008XEN is a single-band Ku-Band PLL LNB with external 10 MHz reference, typ. 0.8 dB noise figure, and rugged IP67 housing. Covering 10.95–12.75 GHz with 10.00 GHz LO, it ensures precise frequency stability for professional SATCOM applications.
Frequency Band: 10.95–12.75 GHz
Output Frequency: 950–2750 MHz
Local Oscillator: 10.00 GHz
LO Stability: External 10 MHz reference
Noise Figure: typ. 0.8 dB, max. 1.0 dB
Gain: typ. 55 dB (50–65 dB range), ≤6 dB p-p flatness
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide grooved
Power: +12 to +24 VDC, 300 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 130 x 60 x 42 mm; Weight: 0.4 kg
Made in Republic of Korea; ECCN: EAR99
1008XEN
- Frequency Band
- Ku-Band
- Frequency Range
- 10.95 – 12.75 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 2750 MHz
- LO Frequency
- 10.00 GHz
- LO Stability
- External Reference
- Noise Figure
- 0.8 dB
- Typical Gain
- 55 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 10.95–12.75 GHz
• LO Reference: External 10 MHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
