Norsat 1008XHAN – Ku-Band Single-Band External Reference PLL LNB, N-Type (50Ω)

Norsat 1008XHAN Single-Band Ku-Band External Reference LNB

The Norsat 1008XHAN is a single-band Ku-Band PLL LNB with 10 MHz external reference input, typ. 0.8 dB noise figure, and stable high gain. Covering 11.70–12.20 GHz with a 10.75 GHz LO, it ensures precise frequency stability and dependable SATCOM performance. It features a 50 Ohm N-type output and rugged WR-75 waveguide input.

Frequency Band: 11.70–12.20 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 10.75 GHz
LO Stability: External Reference (10 MHz, -10 to 0 dBm)
Noise Figure: typ. 0.8 dB, max. 0.9 dB
Gain: typ. 60 dB (55–65 dB range), ≤4 dB p-p flatness
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide grooved
Power: +15 to +24 VDC, 300 mA max
Environmental: -40°C to +60°C
Dimensions: 110 x 42 x 42 mm; Weight: 0.3 kg
Made in Republic of Korea; ECCN: EAR99
