Norsat 1208HGN-2 – Ku-Band Single-Band PLL LNB, N-Type (50Ω)
$374.00
• Input Band: 12.20–12.70 GHz
• LO Stability: ±25 kHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
Security policy
Delivery policy
Return policy
Norsat 1208HGN-2 Single-Band Ku-Band PLL LNB
The Norsat 1208HGN-2 is a single-band Ku-Band PLL LNB with ±25 kHz LO stability and typ. 0.8 dB noise figure, designed for reliable downlinking across 12.20 to 12.70 GHz. It features a 50 Ohm N-type output, WR-75 waveguide input, and IP67-rated protection for dependable SATCOM operation in harsh conditions.
Frequency Band: 12.20–12.70 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 11.25 GHz
LO Stability: ±25 kHz
Noise Figure: typ. 0.8 dB, max. 1.0 dB
Gain: typ. 60 dB (55–65 dB range)
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide
Power: +12 to +24 VDC, 350 mA max
Environmental: -40°C to +60°C, IP67, 0–95% humidity
Dimensions: 128 x 60 x 40 mm; Weight: 0.4 kg
Made in Republic of Korea; ECCN: EAR99
1208HGN-2
- Frequency Band
- Ku-Band
- Frequency Range
- 12.20 – 12.70 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1450 MHz
- LO Frequency
- 11.25 GHz
- LO Stability
- ±25 kHz
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 12.20–12.70 GHz
• LO Stability: ±25 kHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
