Norsat 1008XGN-2 – Ku-Band Single-Band External Reference PLL LNB, N-Type (50Ω)
$660.00
• Input Band: 12.20–12.70 GHz
• LO Reference: External 10 MHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
Security policy
Delivery policy
Return policy
Norsat 1008XGN-2 Single-Band Ku-Band External Reference LNB
The Norsat 1008XGN-2 is a single-band Ku-Band PLL LNB requiring a 10 MHz external reference. Covering 12.20–12.70 GHz with a 11.25 GHz LO, it delivers a typ. 0.8 dB noise figure, stable gain, and rugged IP67-rated housing for reliable SATCOM reception.
Frequency Band: 12.20–12.70 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 11.25 GHz
LO Stability: External Reference (10 MHz, -5 to +5 dBm)
Noise Figure: typ. 0.8 dB, max. 1.0 dB
Gain: typ. 60 dB (55–65 dB range)
Output Connector: N-Type, 50 Ohm
Input: WR-75 waveguide grooved
Power: +12 to +24 VDC, 250 mA max
Environmental: -40°C to +60°C, 0–95% humidity, IP67
Dimensions: 128 x 60 x 40 mm; Weight: 0.4 kg
Made in Republic of Korea; ECCN: EAR99
1008XGN-2
- Frequency Band
- Ku-Band
- Frequency Range
- 12.20 – 12.70 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1450 MHz
- LO Frequency
- 11.25 GHz
- LO Stability
- External Reference
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 12.20–12.70 GHz
• LO Reference: External 10 MHz
• Noise Figure: 0.8 dB
• Output Connector: N-type, 50 Ω
