Norsat 9000HD-3N Single-Band Ka-Band PLL LNB
The Norsat 9000HD-3N is a single-band Ka-Band PLL LNB with ±50 kHz LO stability and a typ. 1.6 dB noise figure, engineered for precise downlinking across 21.20–22.20 GHz. It features a 50 Ohm N-type output, WR-42 waveguide input, and IP67-rated housing for rugged SATCOM performance.
Frequency Band: 21.20–22.20 GHz
Output Frequency: 950–1950 MHz
Local Oscillator: 20.25 GHz
LO Stability: ±50 kHz
Noise Figure: typ. 1.6 dB
Gain: typ. 58 dB, ±2 dB flatness
Image Rejection: 40 dBc min
Output Connector: N-Type, 50 Ohm
Input: WR-42 waveguide
Power: +12 to +24 VDC, 300 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 101.4 x 42.5 x 40 mm; Weight: 0.3 kg
Made in Republic of Korea; ECCN: EAR99
9000HD-3N
- Frequency Band
- Ka-Band
- Frequency Range
- 21.20 – 22.20 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1950 MHz
- LO Frequency
- 20.25 GHz
- LO Stability
- ±50 kHz
- Noise Figure
- 1.6 dB
- Typical Gain
- 58 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- N Type 50 Ohm
