Norsat 9500HDN-4 – Ka-Band Single-Band PLL LNB, N-Type (50Ω)
$898.00
• Input Band: 21.20–22.20 GHz
• LO Stability: ±50 kHz
• Noise Figure: 1.5 dB
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: No
Security policy
Delivery policy
Return policy
Norsat 9500HDN-4 Single-Band Ka-Band PLL LNB
The Norsat 9500HDN-4 is a single-band Ka-Band PLL LNB with ±50 kHz LO stability and a typ. 1.5 dB noise figure, designed for accurate satellite reception across 21.20–22.20 GHz. It features a 50 Ohm N-type output, WR-42 waveguide input, and IP67-rated housing for rugged and reliable SATCOM performance.
Frequency Band: 21.20–22.20 GHz
Output Frequency: 950–1950 MHz
Local Oscillator: 20.25 GHz
LO Stability: ±50 kHz
Noise Figure: typ. 1.5 dB, max. 1.6 dB
Gain: typ. 60 dB (55–65 dB range)
Output Connector: N-Type, 50 Ohm
Input: WR-42 waveguide
Phase Noise: -70 dBc/Hz @1 kHz, -80 dBc/Hz @10 kHz, -95 dBc/Hz @100 kHz
Power: +12 to +24 VDC, 400 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 120 x 60 x 45 mm; Weight: 0.42 kg
Made in Republic of Korea; ECCN: EAR99
9500HDN-4
- Frequency Band
- Ka-Band
- Frequency Range
- 21.20 – 22.20 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1950 MHz
- LO Frequency
- 20.25 GHz
- LO Stability
- ±50 kHz
- Noise Figure
- 1.5 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 21.20–22.20 GHz
• LO Stability: ±50 kHz
• Noise Figure: 1.5 dB
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: No
